Wharfedale Pro T-SUB AX15 B
In stock at supplier
R10,295.00
Everyone loves BASS!
Availability: In stock
Product Description
That is exactly why we have created the T-Sub-AX15B – our 700 W Continuous, 1400 W Peak 15” active subwoofer.
The internal Class D amplifier delivers huge output power into the custom quad-layer 15” Wharfedale Pro LF driver to produce extreme subs and low end pressure into any system.
Built for big bass, the plywood constructed cabinet is rock solid and is protected in durable Rhino Rock paint.
You’ll not only ‘feel’ the T-Sub-AX15B, but you will also see it! A new illuminated WP logo badge subtly glows and adds to the overall on-stage “power” of the new T-Sub.
T-Sub-AX15B is the perfect companion for a Typhon or a Titan active loudspeaker. It also has 75% more power than the current Titan Sub-A15 MKII.
Hold on to your socks! T-Sub-AX15B is going to blow them off!
Key Features
|
|
Around the front
- 15mm plywood construction
- Full face steel grille
- 15″ Quad layer driver
- 3.0″ voice coil
- Illuminated LED front logo badge
- Two practical and handy handles
- 35mm top pole socket
- (and Rhino Rock durable finish)
and around the back
- Class D amplification with convection cooling
- Comprehensive limiting protection
- Polarity switching
- Adjustable low pass filter
- Balanced inputs
- Balanced outputs
T-Sub-AX15B…..destroying its competitor by +75%
Here at Wharfedale Pro, we are passionate about our products!
But there comes a time when we have to admit defeat!
Our original Titan Sub A15 MKII cannot stand up to T-Sub-AX15B !!! 🙁
T-Sub-AX15B is +75% more powerful than our classic Titan Sub A15 MKII.
SPECIFICATIONS
| Model Name | T-Sub-AX15B |
|---|---|
| System Type | Active 15″ Subwoofer |
| Frequency Response (+/-3dB) | 45Hz-200Hz |
| Sensitivity @ 1W / 1m) | 97dB |
| Maximum SPL (peak@1m) | 129dB |
| Low Frequency Transducer | |
| Size (mm / inches) | 404mm / 15″ |
| Coil Size (mm / inches) | Quad layer 3.0″ |
| Impedance | 4Ω |
| Amplifier | |
| Low-Frequency Power Amplifier (Class D) | 700w Continuous / 1400w Peak |
| Crossover Frequency | LPF 80-200Hz (adjustable) |
| Controls | |
| Amplifier Protection | Yes |
| Power On Protection | Power switch on / off mute |
| Thermal Protection | Amplifier shutdown, auto reset |
| Driver Protection | Yes |
| DC Protection | Yes |
| Short Protection | Yes |
| Limiter Indicator | Red LED |
| Input type | Balanced |
| Input Connector | Female XLR |
| Input Impedance | 47KΩ Balanced |
| Maximum Input Level | 5V |
| Input Sensitivity | -10dB |
| Input Connectors | Female XLR |
| Line Output Connector | Male XLR |
| Phase Switch Selection | 0° / 180° |
| AC Power details | |
| Power Supply | SMPS |
| AC Power Options | 100V-120V and 200V-240V |
| Power Indicator | Green(back) / Blue logo(front) |
| Enclosure | |
| Enclosure Material | 15mm Plywood |
| Colour | Black |
| Grille | 1.5mm steel |
| Pole Mount(Top) | 35mm |
| Dimensions (Unpacked): | |
| Height | 591mm / 23.27″ |
| Width | 454mm / 17.9″ |
| Depth | 523.9mm / 20.63″ |
| Dimensions (packed): | |
| Height | 689mm / 27.1″ |
| Width | 544mm / 21.4″ |
| Depth | 610mm / 24.0″ |
| Weight | |
| Net Weight (kg / lbs) | 25.7kg / 56.5lbs |
| Gross Weight (kg / lbs) | 29.5kg / 64.9lbs |
