Rane SEVENTY A-TRAK Signature Edition

Name: Rane SEVENTY A-TRAK Signature Edition
Brand: Rane DJ
Availability: OutOfStock

0 customer reviews

OUT OF STOCK

Rane SEVENTY A-TRAK Signature Edition - Image 2

Rane SEVENTY A-TRAK Signature Edition - Image 3

Rane SEVENTY A-TRAK Signature Edition - Image 4

Rane SEVENTY A-TRAK Signature Edition - Image 5

Rane SEVENTY A-TRAK Signature Edition - Image 6

View details

R39,295.00

Rane SEVENTY A-TRAK Signature Edition DJ Mixer

Availability: Out of stock

Add to wishlist

Add to quote

Categories: DJ Gear DJ Mixers Z3 Brand: Rane DJ

Product Description

Pushing the Boundaries of Turntablist Performance

Sonic innovation in a battle-tested frame.

Key Features

Stunning Custom Design – The exterior of the SEVENTY A-TRAK SIGNATURE EDITION features a stunning silver finish than gleams beneath the aluminum-capped rotary-styled knobs and encoders.
Enhanced Capabilities – Fader FX transforms the channel volume faders into linear controllers for performance effects like Filter, Roll, Pitch, Ring Modulator, and four types of Oscillators.
Sonic Innovation – The sound curve and frequency response of the mixer was handcrafted by A-Trak himself, increasing the depth of the low end to ensure that the high-quality audio matches his signature sound.

Performance-Enhancing Fader-FX

Effects

Filter
Roll
Pitch
Ring Modulator

Tone Generators

Sine
Sawtooth
Square
Triangle

With Fader FX, the SEVENTY A-TRAK SIGNATURE EDITION DJ mixer’s upfaders are transformed into linear controllers for performance effects like Filter, Roll, Pitch, Ring Modulator, and four types of Oscillators. DJs can dive into the settings of these Fader FX options to change root keys, octaves, and more.

Built For Battle

Built upon the solid foundation of the SEVENTY, the SEVENTY A-TRAK SIGNATURE EDITION features the same solid-steel construction, 3 x MAG FOUR faders, and MPC-style performance pads.

Custom Serato Sticker Lock Vinyl

The SEVENTY A-TRAK SIGNATURE EDITION includes 10″ Serato Sticker Lock Control Vinyl with custom A-Trak and Fools Gold stickers.

General Specifications

Digital Audio
Converters	AKM High Definition Audio; 24-bit PCM, 48 kHz
Digital Signal Processing	32-bit, floating point, double precision
Dynamic Range (A-weighted, unity gain)	ADC DAC CD Input to Analog Output CD Input to USB Output USB Input to Analog Output	114 dB 114 dB 114 dB 114 dB 114 dB
Inputs
Microphone 1/2 (Combo XLR/1/4″ [6.35 mm] TRS, Mic/Line switchable)	Analog Gain Maximum Input Gain Trim	30 dB (Mic), 4.75 dB (Line) 0.126 Vrms (Mic), 2.3 Vrms (Line) Off to +20 dB (unity at center)
Aux Inputs 1/2 (RCA stereo pairs)	Maximum Input Dynamic Range (A-weighted)	4 Vrms 114 dB
CD/Phono Inputs 1/2 (RCA stereo pairs, switchable)	CD Maximum Input Dynamic Range (A-weighted) Phono RIAA Curve Gain (@ 1 kHz) Maximum Input (@ 1 kHz)	Line 4 Vrms 114 dB RIAA +0.1/-0.2 dB 30 dB 126 mV
Session Input (RCA stereo pair)	Maximum Input Dynamic Range (A-weighted)	4 Vrms 114 dB
Outputs
Main Outputs (XLR)	Frequency Response Maximum Output THD+N (@ 1 kHz, 4 Vrms)	20 Hz to 20 kHz (± 0.2 dB) 8 Vrms 0.002%
Booth Outputs (1/4″/6.35 mm TRS)	Frequency Response Maximum Output THD+N (@ 1 kHz, 4 Vrms)	20 Hz to 20 kHz (± 0.2 dB) 8 Vrms 0.002%
Session Outputs (RCA stereo pair)	Frequency Response Maximum Output THD+N (@ 1 kHz, 2 Vrms)	20 Hz to 20 kHz (± 0.2 dB) 4 Vrms 0.002%
Headphone Outputs (1/4″/6.35 mm and 1/8″/3.5 mm TRS)	Maximum Output Voltage THD+N (@ 1 kHz, 2 Vrms) Output Power Controls	4 V (no load) 0.003% 96 mW (50 ohms) On/Off muting
General
Display	1.6” OLED (diagonal)
Pads	(16) velocity-sensitive multi-color back-lit pads (8 per deck, 10 modes each)
Faders	(3) MAG FOUR tension-adjustable faders (2 channel/line faders, 1 crossfader)
Connectors	(2) XLR outputs (Main) (2) 1/4” (6.35 mm) TRS outputs (Booth) (4) RCA stereo input pairs (Deck 1–2) (2) XLR / 1/4” (6.35 mm) TRS inputs (Mic 1–2) (1) RCA stereo input pair (Session) (1) RCA stereo output pair (Session) (1) 1/4” (6.35 mm) TRS output (Headphones) (1) 1/8” (3.5 mm) TRS output (Headphones) (2) USB Type-A ports (Deck 1–2 USB Controllers) (2) USB Type-B ports (1) IEC power cable input
Power	Connection: IEC Voltage: 100–240 V, 50/60 Hz Consumption: 30 W
Dimensions (width x depth x height)	11.2” x 17.5” x 4.13” 285 x 445 x 105 mm
Weight	12.3 lbs. 5.6 kg
