Linear 9 118 Sub BA

0 customer reviews
Check stock before ordering
View details

R86,245.00


The LINEAR 9 118 Sub BA is a powerful 18″ dual vented bandpass subwoofer. The generous size of the cabinet allows for an exceptionally high sound pressure level with a low cut-off frequency at the same time.

Availability: In stock

Add to wishlist
Add to quote
Reviews (0)

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

SKU: LINEAR 9 118 SUB BA Category: Brand:

Product Description

Powerful and Deep

The LINEAR 9 118 Sub BA is a powerful 18″ dual vented bandpass subwoofer. The generous size of the cabinet allows for an exceptionally high sound pressure level with a low cut-off frequency at the same time. This makes this subwoofer not only a perfect partner for powerful full-range speakers, but also an ideal sub low extension for the direct-radiating LINEAR 9 118 Sub A. Thanks to the integrated presets, cardioid setups can be implemented quickly and easily. The LINEAR 9 118 Sub BA is compatible with all LINEAR 9 Mid/High models.

General Specifications

  • Max. SPL @ 10% THD:  134 dB half space (40 Hz – 110 Hz averaged)
  • Max. SPL peak @ 10 % THD:  136 dB half space
  • Frequency response +/-3 dB:  38 Hz – X-over
  • Frequency Response -10 dB:  31 Hz – X-over
  • Power Amp Output (Peak Power):  1100 W
  • Amp Type:  Class D
  • LF Driver:  1X 18″, 4″ voice coil
  • Maximum Input Level:  +20 dBu
  • Analog Inputs:  2X XLR combo balanced
  • Analog Thru: 2X XLR balanced
  • DSP Out:  Balanced
  • Network Port:  Ethercon RJ45, 1x In, 1x Thru
  • Filter Presets:  Front, Cardioid 1:1, Cardioid 2:1, Remote
  • Remote Software:  DSP CONTROL (Windows, macOS)
  • DSP Functions:  Fully parametric 10-band EQ with variable filter characteristics, Low-Pass Filter, Polarity, Level, Delay, Limiter, Mute
  • Sample Rate:  96 kHz
  • System Latency:  Less than 2.6 ms
  • Mains Connector:  1x Powercon NAC3 In, 1x Powercon NAC3 Thru, 100–240 V
  • Power Consumption:  1.9 A / 100–240 V nominal according to EN 62368-1
  • Pole Mount:  1x M20
  • Carrying Handles:  8x MultiGrip
  • Housing:  Birch multiplex
  • Finish:  PU coating black
  • Front Grille:  2 mm metal grille backed with black acoustic foam
  • Dimensions (WxHxD):  111cm X 56cm X 69cm / 43-9/32″ X 22-3/64″ X 27-11/64″
  • Weight:  63.5 kg / 139.9lbs
