LF DRIVER SIZE : 165mm (6.5")
HF DRIVER SIZE : 25mm (1")
HF DRIVER TYPE : Soft dome
CROSSOVER : 1425Hz 4th order acoustic Linkwitz-Riley
OK FOR USE NEAR MAGNETICALLY SENSITIVE EQUIPMENT : Yes
INPUT SENSITIVITY (-10dBV INPUT) : 92dB / 1m
POWER CONFIGURATION : Bi-amplified
HF DRIVER POWER AMP 56W, : Class-D
LF DRIVER POWER AMP 56W : Class-D
FREQUENCY RESPONSE (±3dB) : 47Hz – 20kHz
FREQUENCY RANGE (-10dB) : 39Hz – 24kHz
LOW FREQUENCY EXTENSION (-10dB) : 39Hz
MAXIMUM CONTINUOUS SPL : 92dB
MAXIMUM PEAK SPL : 110dB
MAXIMUM PEAK INPUT LEVEL (-10dBV / +4dBu) : +6dBV / +20.3dBu
SYSTEM DISTORTION CRITERIA : <10% THD at maximum output with full compressor / limiter engagement
ELECTRICAL DISTORTION CRITERIA : 0.2% THD @ 1kHz / 2.83VRMS output; <1% THD @ 1kHz, full rated output
SIGNAL TO NOISE RATIO : 75dBA (A-Weighted), 70dBr (unweighted), relative to 2.83VRMS output
COVERAGE HORIZONTAL x VERTICAL : 120° x 90°
ANALOG INPUT TYPES : 1 x XLR female, 1 x TRS female, balanced
HF TRIM CONTROL : -2dB, 0dB, +2dB
BOUNDARY EQ : LF Shelf @ 50Hz: -3dB, -1.5dB, 0dB
AC INPUT VOLTAGE : 100 – 240VAC (±10%), 50 / 60Hz
ENCLOSURE TYPE : Ported
ENCLOSURE CONSTRUCTION : 15mm MDF
ENCLOSURE FINISH : Matte black PVC
BAFFLE CONSTRUCTION : Injection-molded structural ABS
CABINET DIMENSIONS (H x W x D) : 361 x 224 x 282mm (14.2" x 8.8" x 11.1")
DISPLAY CARTON (H x W x D) : 408 x 285 x 328mm (16.1" x 11.2" x 12.9")
SHIPPING CARTON (H x W x D) : 418 x 292 x 338mm (16.5" x 11.5" x 13.3")
NET WEIGHT : 6.1 kg (13.42 lbs)
SHIPPING GROSS WEIGHT : 7.25 kg (15.95 lbs)
|
