AVLINK – HDNK2 HDMI OVER CAT5/6 EXTENDER

100m Range extender
OUT OF STOCK
View details

R2,130.00


100m Range extender

Availability: Out of stock

Add to wishlist
Add to quote
Categories: Brand:

Product Description

An extender kit that allows 4K and FHD HDMI signals to be sent between devices at distances of up to 100m using a single shielded network cable. The Extender kit works using a single cat5e or cat6 (recommended) cable instead of HDMI cable to transmit high-definition signals over a long distance, vastly reducing your costs but without reducing your picture quality. The built in IR function enables simple control of transmission devices remotely and an audio extraction function allows connection to headphones, speakers and amplifiers using a 3.5mm audio cable (not supplied).

HDMI version: 1.4a

Max. range: 100m

Video format: Up to 3840 x 2160 @ 60Hz

Audio format: Supports DTS-HD/Dolby-trueHD/DTS/Dolby-AC3/DSD

Max. cable length: HDMI (input & output) ?15m AWG26 standard cable

Max. bandwidth: 350MHz

Max. baud rate: 3×3.4Gbps

Max. working current: 350mA (TX) and 200mA (RX)

Power supply: 5Vdc, 1000mA

Dimensions: 82x45x18mm (each unit)

Weight: 120g (each unit)
